Lithium batteries to terminate a tape using PET as substrate, the substrate is coated with high special rubber glue electrolyte of lithium battery, specially used in the insulation protection of lithium-ion batteries and other parts of the termination and fixed.

Product Name: stop adhesive tape

Product type: lithium electrode special adhesive tape for ear

Features: insulation, anti chemical solvent resistance, electrolyte, high adhesion, docile good, no residue.

Application: extensive lithium ion battery ear bandage,

technical parameter

________________________________________

Substrate: pet

Color: Green

Rubber series: Rubber

Specifications

Wide (mm) 100M 10MM

Length (m): 100M-200M

Thickness (mm):0.22 0.03

Adhesive force (N/25mm): 4.65 (#20) /7.35 (#30)

Tensile strength (N/25mm): 60 (#20) /110 (#30)

Elongation (%) 140 (#20) /150 (#30)

Temperature resistance (degree of temperature): 100~130 degree

Uses:

PET green glue is coated with high temperature silicone pressure sensitive adhesive on PET substrate. It has good adhesion, strong retention in 200 degree high temperature environment, and no residual glue and no breakage.

1, mainly applicable to computer chassis, cabinets and other high-temperature powder is not sprayed, paint shielding protection;

2. It is also suitable for shielding and insulation of electronic products, automobile industry, painting and other products during high temperature spraying;

3, printed circuit board, electronic parts, resistors and capacitors fixed during production and PCB plate immersion process to cover the gold finger part and prevent electroplating liquid immersion and pollution, PCB gold shield protection;

4, household appliances, machinery, electronics and other industries need high temperature spray protection, high temperature binding fixed role.

5, the use of parting paper connector (also known as: feeder tape)
